Small power air-cooled standardized lithium hydrogen power generation module
SMALL POWER STANDARDIZED HYDROGEN POWER MODULE
Flexible and expandable 3kW air-cooled hydrogen lithium hybrid system standard module
Suitable for scenarios such as small drones, light vehicles, low-power emergency power supplies, small machinery, and light forklifts
Hydrogen free bottle version
Flexible expansion, independent range extension
Built in hydrogen bottle version
Convenient hydrogen exchange, worry free battery life
Millisecond level power response and power adaptation
Flexible expansion（3kW*N）
5V、12V、48V Multi voltage output
Long battery life, small size, fast deployment, plug and play, one click start stop
Push pull hydrogen cylinder storage compartment, quick hydrogen exchange (supports external hydrogen cylinder)
Touch screen operation, real-time monitoring of operating status, and real-time regulation
Specification parameters
rated output voltage
48V（Optional）
Rated output power
3kW
Peak output power
5kW
Built in hydrogen bottle version
model
SeePack-Sys-3000A
weight
35 kg
Rated current
0-2A / 0-10A / 0-12A / 0-60A
size
544×370×368 mm
rated voltage
5V / 12V / 48V / 220V
Hydrogen free bottle version
model
SeePack-Sys-3000A
weight
35 kg
Rated current
0 – 60 A
size
544×370×368 mm
rated voltage
48V
General specifications
Fuel cell type
PEMFC
Output parameters
rated power
3000 W
peak power
5000 W
Hydrogen standard
hydrogen purity
≥ 99.999% (CO≤1 PPM)
Hydrogen consumption rate
45 NL/min （rated power）
Hydrogen supply pressure
55 ± 5 kPa
Environmental requirements
operation temperature
0 – 40 ℃
Storage conditions
condensation
Cooling method
Forced air cooling
Working humidity
20 – 95% RH, No condensation
Operating noise
≤ 70 dB
